FOCUS CNC - FBL-460L

Sturdy box way model capable of low speed heavy-duty machining.

Armed with the latest Fanuc control, high resolution LCD screen, and multi-functional interface, for the best possible operating environment.
High rigidity box way with scrapped slide way and precision oil network design for superb transmission efficiency.
The 45° slant bed structure with a low center of gravity, for enhanced machining accuracy.

Powerful Turret

Fitted with powerful hydraulic turret for heavy duty machining. Structured with rigid mechanical parts to meet with strict requirements for high machining efficiency.

High Torque Spindle Transmission System

Two-stage star gearbox for speed change featuring full throttle high torque output or low speed for high torque turning properties.
Imported highly intensive pitch type belt provides solid grip without slipping. Outfitted transmission device produces little noise and has good heat transmission for good heat radiation. Also features easy maintenance and adjustment.

Programmable Tailstock System

High rigidity machine body highlights shock-dampening property. Z-axis saddle driven by programs for automatic control of tailstock movement.
Optional rotating arbor available for greater workload.

CAPACITY	METRIC	IMPERIAL
Distance between centres	2200 mm	86.61"
Swing over bed	840 mm	33.07"
Swing over saddle	650 mm	25.59"
Max turning diameter	ø650 mm	ø25.59"
Max turning length	1992 mm	78.42"
Max bar diameter	ø140 mm	ø5.51"
HEADSTOCK
Chuck diameter	ø381 mm	ø15"
Spindle nose	A2-15	A2-15
Spindle hole diameter	ø153 mm	ø6.02"
Spindle speed	1400 rpm	1400 rpm
Spindle run out	0.003 mm	0.0001"
TRAVELS
X-Axis travel	360 mm	14.17"
Z-Axis travel	2000 mm	78.74"
FEEDRATE
Rapid traverse X-Axis	18 M/min	708.66"/min
Rapid traverse Z-Axis	18 M/min	708.66"/min
TURRET
Number of tools	10 (*12)	10 (*12)
Turning tool size	32 x 32 mm	1.25 x 1.25"
Boring tool size	50 mm	1.96"
Tool system	–	–
Max rotary tool speed	–	–
TAILSTOCK
Tailstock travel	2000 mm	78.74"
Quill travel	120 mm	4.72"
Quill diameter	ø110 mm	ø4.33"
Quill taper hole	MT5	MT5
Quill drive	hydraulic	hydraulic
Tailstock positioning	programmable	programmable
MOTORS
Spindle motor (30 min rating)	upgrade 30kW (37kW)	upgrade 40hp (49hp)
Rotary tool motor	–	–
X-Axis Servo motor	4kW	5.36hp
Z-Axis Servo motor	4kW	5.36hp
GENERAL
Electrical approval	CSA SPE-1000	CSA SPE-1000
Power required	30kVA (*45kVA)	30kVA (*45kVA)
Voltage required	600V or 220V	600V or 220V
Coolant pressure	9.5 bar	137 psi
Coolant tank capacity
Hydraulic tank capacity
CONTROLLER
CNC Control	FANUC	FANUC
*Option
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice. Refer to literature for tool interference considerations.
