CHEVALIER - FVL-8

CNC Vertical Turning Lathe Box Way

Features

The FVL-CNC VTL Series is perfect for automation or cell manufacturing and the simplified fixture design is excellent for turning irregular shaped workpieces.

  • Easy loading and unloading of workpieces.
  • Minimum clamping required because the workpiece weight sets and holds the part in place. No more workpiece warpage caused by hard clamping.
  • Available with gang type, single turret or double turret tooling configuration for mixed volume production.
  • It is ideal for high speed cutting on materials like steel, copper, aluminum and casting. The machining accuracy of the workpiece is high.
  • High speed double turret can do individual or simultaneous turning for faster cycle times.
  • Optional C-Axis and live tooling VDI turret can perform multiple operations in one setup.
  • Heavy duty spindle uses large diameter NN double-row cylindrical bearings, delivering runout accuracy within 0.0001“ (0.003mm).
  • A relatively small foot print saves valuable work space - perfect for automation or cell manufacturing.

Chevalier FVL-8 12 20 24 Series (201708).pdf
  Focus FVL-8,12,20,24'Series Highlights

Specifications: CHEVALIER - FVL-8

Related Products:

CAPACITY METRIC IMPERIAL
Max swing diameter ø400 mm ø15.74"
Max turning diameter ø220 mm ø8.66"
Max turning height 430 mm 16.92"
SPINDLE
Chuck size ø203.20 mm ø8"
Spindle nose A2-6 A2-6
Spindle speed 4000 rpm 4000 rpm
Spindle bearing I.D. 100 mm 3.93"
Distance from spindle nose to floor 864 mm 34.01"
Distance from center of spindle to the front cover of machine 340 mm 13.38"
V.D.I spindle speed – –
TURRET
Turret type gang gang
Number of tools 2 tools 2 tools
Number of turret – –
O.D. Tool shank size 19.05 x 19.05 mm 0.8 x 0.8"
I.D. Tool shank size 31.75 mm 1.30"
STROKE
X-Axis stroke 235 mm 9.25"
Z-Axis stroke 430 mm 16.92"
FEEDRATES
Balancing device for vertical axis pneumatic balance pneumatic balance
X-Axis rapid speed 20 M/min 787.40"/min
Z-Axis rapid speed 20 M/min 787.40"/min
Ball screw diameter ø28 mm ø1.10"
Lead pitch 6 mm 0.23"
TAILSTOCK
Tailstock stroke – –
Quill stroke – –
Quill taper – –
Quill driving system – –
The indexing way of tailstock – –
MOTOR
Spindle motor 9kW / 11kW (αP18) 12.06 / 14.75hp (αP18)
V.D.I spindle motor – –
Feeding motor (X/Z) 1.6kW (α8i) 2.14hp (α8i)
Drilling and tapping motor – –
Turret motor – –
Lubrication motor 0.08kW 0.10hp
Hydraulic motor 1.5kW 2hp
Coolant motor – –
Chip disposal motor 1.1kW 1.47hp
Water gun motor 0.75kW 1hp
TANK CAPACITY
Hydraulic tank 30 L 7.9 US gal
Lubrication tank 3 L 0.79 US gal
Coolant tank 300 L 79.25 US gal
GENERAL
Electrical approval CSA SPE-1000 CSA SPE-1000
Power required 20kVA 20kVA
Voltage required 600V or 220V 600V or 220V
Air pressure required 5.5 kg/cm² 79 psi
Machine weight 3600 kg 7920lb
CONTROLLER
CNC Control FANUC FANUC
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.

Standard Accessories

  • 8" 3 Jaw hydraulic chuck
  • Tool holder 2pcs ID holder, 2pcs OD holder
  • ID sleeve 6pcs YC32-6A, 8A, 10A, 12A, 16A & 20A
  • Drill sleeve 2pcs MT2, MT3
  • Automatic lubrication system
  • Chip conveyor with coolant tank
  • Chip cart
  • Hydraulic unit
  • Oil skimmer
  • Electrical cabinet heat exchanger
  • LED Work light
  • Levelling bolts, nuts & pads
  • Tool kit

Included Accessories

  • Transformer

Optional Accessories

  • 10" 3 Jaw hydraulic chuck
  • 2 step speed gear box (ZF-made in Germany)
  • Clean gun device for workpiece
  • Clean water gun for working area (shared pump)
  • Clear water gun for working area (independent pump)
  • Air clean gun
  • Coolant through type of the tool holder
  • Chip conveyor roller type (include water machine)
  • Spindle chiller
  • Oil mist collector
  • Dust collector
  • Electrical cabinet air conditioner
  • Automation device
  • Crane
  • CE Specification
