FIRST - MCV-1100

CNC Vertical Machining Centre

Features

  • All major machine parts are Meehanite cast iron.
  • Box type slideways with long lasting accuracy even under heavy cutting and high speed machining.
  • All 3-axes equipped with preloaded ballscrews directly driven with servo motors to eliminate backlash between bearings and ballscrews for excellent feeding accuracy.
  • Rigid direct drive spindle unit achieves high accuracy.
  • Top open front door design allows easy access for setups.

First MCV-850, 1100 (A01 12051802).pdf

Specifications: FIRST - MCV-1100

Related Products:

TRAVELS METRIC IMPERIAL
X-Axis travel 1100 mm 43.30"
Y-Axis travel 600 mm 23.62"
Z-Axis travel 560 mm 22.04"
Distance from spindle nose to table top 100 - 660 mm 3.93 - 25.98"
Guideway type X-Axis box way box way
Guideway type Y-Axis box way box way
Guideway type Z-Axis box way box way
TABLE
Table working surface 1300 mm x 600 mm 51.18 x 23.62
T-slot number (width x pitch) 6 (18 x 100 mm) 6 (0.7 x 3.93")
Max table load 1000 kg 2204 lb
FEEDRATE
Rapid traverse X-Axis 20 M/min 787.40"/min
Rapid traverse Y-Axis 20 M/min 787.40"/min
Rapid traverse Z-Axis 15 M/min 590.55"/min
Cutting feedrate 1-10000 mm/min 0.04-394"/min
Min input increment 0.001 mm 0.0001"
SPINDLE
Drive system direct drive direct drive
Spindle motor (30 min rating) 11kW (15kW) 15hp (20hp)
Taper BBT40, Big Plus BBT40, Big Plus
Speed range upgrade 10000 rpm upgrade 10000 rpm
Drive range infinitely variable infinitely variable
Max spindle torque
TOOL CHANGER - Arm Type
Tool magazine capacity upgrade 32 tools upgrade 32 tools
Max tool weight 7 kg 15.43 lb
Max tool length 300 mm 11.81"
Max tool diameter ø95 mm ø3.74"
Max tool diameter (adjacent empty) ø160 mm ø6.29"
Tool selection random, bi-directional random, bi-directional
Tool to tool change time 1.8 sec 1.8 sec
DRIVE MOTORS
Feed drive (torque) X-Axis 3kW (20Nm) 4hp (20Nm)
Feed drive (torque) Y-Axis 3kW (20Nm) 4hp (20Nm)
Feed drive (torque) Z-Axis 3kW (36Nm) 4hp (36Nm)
GENERAL
Electrical approval CSA SPE-1000 CSA SPE-1000
Power required 25kVA 25kVA
Voltage required 600V or 220V 600V or 220V
Air pressure required 5-7 bar 75-110 psi
Coolant tank capacity 486 L 128.38 US gal
CONTROLLER
CNC Control FANUC FANUC
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.

Standard Accessories

  • Automatic lubrication system
  • Enclosed splash guard
  • Coolant system
  • Coolant tank and chip collector
  • Coolant around spindle
  • Chip flush/wash system
  • Removeable MPG manual pulse generator
  • Electric cabinet exhaust fan
  • Alarm light (3-color)
  • LED Work light
  • Levelling bolts, nuts and pads
  • Tool kit

Included Accessories

  • #40 32-tool CAM type ATC
  • 10000rpm direct drive spindle
  • Set of pull studs
  • Coolant and air gun
  • Coolant through spindle system (20 bar)
  • External air blast
  • Spindle oil chiller
  • Oil skimmer
  • Chip conveyor-spiral (screw) type front L side discharge + bin
  • 4th axis connector ready
  • Automatic power off
  • Door inter-lock safety switch
  • Transformer

Optional Accessories

  • CAT40 Tool shank
  • CAT50 Tool shank
  • #40 40-tool CAM type ATC (max tool dia 76mm & 127mm adj empty)
  • #50 24-tool CAM type ATC, 6000 rpm/8000 rpm, belt drive
  • #50 30-tool CAM type ATC, 6000 rpm/8000 rpm, belt drive
  • #50 40-tool CAM type ATC, 6000 rpm/8000 rpm, belt drive
  • Note: Maximum tool diameter may change with alternate tool magazine option.
  • Bigger spindle motor 15kW (18.5kW)
  • Gear box
  • Coolant through spindle system (50 bar)
  • Air through spindle system
  • Oil mist collection system
  • Chip conveyor-flat type front L side discharge + bin
  • 4th axis rotary table
  • 4th + 5th axis connector ready
  • 4th + 5th axis rotary table
  • Automatic tool measuring device
  • Automatic workpiece measuring device
  • Linear scale
