CNC Vertical Machining Centre


Dah Lih continues its tradition, providing a strong, rigid, reliable, compact machine for a long term return.

  • Major casting parts designed and analyzed by advanced “Finite Element Analysis” for optimum structural rigidity and accuracy.
  • All structural parts manufactured from high quality cast iron, assuring best possible stability of the structure.
  • Extra wide column bottom allows a rigid fastening to the machine base thus providing a solid foundation for precision machining.
  • Symmetrical construction of box type column and base combined with scientific cross ribs reinforcement results in greater structural rigidity and reduces thermal deformation to a minimum.
  • The extra-large span between Y-axis slideways maintains gravity point in machine base when table travels on X-axis, thus preventing overhang problems on saddle and increasing machining stability.
  • Compact construction but still offers great machining capacity.
  • Coolant jets around spindle nose provide excellent cooling for cutting tool and workpiece.
  • Chip augers located on both sides of base for quick chip removal effectively prevents thermal deformation of the structure through chip heat.

Specifications: DAH LIH - MCV-1200BA

Related Products:

X-Axis travel 1200 mm 47.24"
Y-Axis travel 600 mm 23.62"
Z-Axis travel 600 mm 23.62"
Distance from spindle nose to table top 150 - 750 mm 5.90 - 29.52"
Distance from spindle centre to column face 660 mm 26"
Guideway type X-Axis linear roller linear roller
Guideway type Y-Axis linear roller linear roller
Guideway type Z-Axis box box
Table working surface 1300 x 640 mm 51.18" x 25.19"
T-slot number (width x pitch) 5 (18 x 125 mm) 5 (0.7 x 4.92")
Max table load 1000 kg 2204 lbs
Rapid traverse X-Axis 30 M/min 1181.10"/min
Rapid traverse Y-Axis 30 M/min 1181.10"/min
Rapid traverse Z-Axis 18 M/min 708.66"/min
Cutting feedrate 0 - 10 M/min 0.04-394"/min
Min input increment 0.001 mm 0.0001"
Drive system direct drive direct drive
Spindle motor (30 min rating) 7.5kW(11kW) 10hp(14.7hp)
Taper BBT40, Big Plus BBT40, Big Plus
Speed range upgrade 12000 rpm upgrade 12000 rpm
Drive range infinitely variable infinitely variable
Max spindle torque 70Nm 70Nm
Tool magazine capacity 24 tools 24 tools
Max tool weight 7 kg 15.43 lb
Max tool length 300 mm 11.81"
Max tool diameter ø90 mm ø3.54"
Max tool diameter (adjacent empty) ø180 mm ø7.08"
Tool selection random random
Tool to tool change time 3 sec 3 sec
Feed drive X-Axis 2.5kW 3.4hp
Feed drive Y-Axis 2.5kW 3.4hp
Feed drive Z-Axis 3kW 4hp
Electrical approval CSA SPE-1000 CSA SPE-1000
Power required 25kVA 25kVA
Voltage required 600V or 220V 600V or 220V
Air pressure required 5-7 bar 75-110 psi
Coolant tank capacity 365 L 96.42 US gal
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.

Standard Accessories

  • 24-tool CAM type ATC
  • Automatic lubrication equipment
  • Enclosed splash guard
  • Coolant and air gun
  • Coolant around spindle
  • External air blast
  • Spindle oil chiller
  • Chip conveyor-spiral type, both sides of base
  • Remote manual pulse generator
  • Automatic power off
  • Electric cabinet heat exchanger
  • Call light (3-color)
  • LED Work light
  • Levelling bolts, nuts & pads
  • Tool kit
  • Transformer

Included Accessories

  • 12000 rpm direct drive spindle
  • Set of pull studs
  • Coolant through spindle (20 bar)
  • Air through spindle system
  • Oil skimmer
  • Chip flush/wash system
  • Chip conveyor-spiral (screw) type front L side discharge + bin
  • Linear roller guideway (X,Y)
  • 4th axis connector ready
  • Upgraded driver
  • Door inter-lock safety switch

Optional Accessories

  • CAT40 Tool shank
  • 30-tool CAM type ATC
  • 32-tool CAM type ATC
  • 40-tool CAM type ATC
  • Note: Maximum tool diameter may change with alternate tool magazine option.
  • 8000 rpm belt drive spindle
  • 15000 rpm direct drive spindle
  • 15000 rpm built-in type spindle
  • Coolant through spindle (50 bar)
  • Coolant through ball screw
  • Oil mist collection system
  • Chip conveyor-flat type front L side discharge + bin
  • Linear roller guideway (Z)
  • 4th axis rotary table
  • 4th + 5th axis connector ready
  • 4th + 5th axis rotary table
  • Automatic tool length measuring device
  • Automatic workpiece measuring device
  • Linear scale
