MICROWEILY - TY-1845S

One piece Meehanite cast base.
Hardened and precision ground gears and bed ways.
The cross slide is induction hardened to HRC 52° and precision ground.
The slideways between the saddle and bed are TURCITE B coated, reducing friction and saving on power consumption.

Microweily Company Profile

CAPACITY	METRIC	IMPERIAL
Distance between centres	1145 mm	45.07"
Swing over bed	460 mm	18.11"
Swing over cross slide	288 mm	11.33"
Swing in gap	640 mm	25.19"
Length of gap in front of face plate	180 mm	7.08"
Centre height	230 mm	9.05"
Bed width	300 mm	11.81"
HEADSTOCK
Spindle bore	58 mm	2.28"
Spindle nose	D1-6	D1-6
Spindle taper in nose	MT6	MT6
Spindle taper in sleeve	MT4	MT4
Speed range (12-step)	30 - 2000 rpm	30 - 2000 rpm
CARRIAGE & COMPOUND
Cross slide travel	265 mm	10.43"
Compound rest travel	135 mm	5.31"
Leadscrew diameter, thread	ø1 3/8", 4 TPI	ø1 3/8", 4 TPI
THREADS & FEEDS
Imperial pitches 60 Pos	2-112 TPI	2-112 TPI
Metric pitches 60 Pos	0.2-14 mm	0.2-14 mm
Diametral pitches 50 Pos	4-112 DP	4-112 DP
Module pitches 50 Pos	0.2-7 MP	0.2-7 MP
Cross feeds 50 Pos	0.0185-0.52 mm/rev	0.0007-0.01935"/rev
Longitudinal feeds 50 Pos	0.037-1.04 mm/rev	0.0014-0.0387"/rev
TAILSTOCK
Quill diameter	ø60 mm	ø2.36"
Quill travel	150 mm	5.90"
Quill taper	MT4	MT4
MOTORS
Spindle motor	7 1/2hp	7 1/2hp
Coolant pump	1/8hp	1/8hp
GENERAL
Electrical rating	600V 10Amp 3Ph 60Hz	600V 10Amp 3Ph 60Hz
Electrical approval	CSA SPE-1000	CSA SPE-1000
PHSR exemption letter	valid in Ontario	valid in Ontario
Weight	1810 kg	3990 lb
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.
