CHEVALIER - FSG-818SP

Table traverses on linear ball bearings and D2 hardened & ground guideways.
Reinforced ribbed column with hardened & ground guideway system.
Elevating & cross-feed leadscrews are hardened & ground.
Saddle travels on Turcite-B coated and hand scraped double V guideways.
Vertical hand wheel at waist level for convenient operation.
Permanently lubricated and sealed cartridge-type spindle uses two pairs of class 7 (P4) angular contact ball bearings.
2hp dynamically balanced spindle motor.
Automatic lubrication system.
Meehanite cast iron base.
A mirror surface can be accomplished on these machines accurately and efficiently.

CAPACITY	METRIC	IMPERIAL
Max grinding length - longitudinal	500 mm	19"
Max grinding width - cross	220 mm	8.7"
Table surface to spindle centre	500 mm	19"
Magnetic chuck size	200 x 450 mm	8 x 18"
Grinding wheel diameter	ø203 mm	ø8"
Grinding wheel width	12.7 - 25.4 mm	1/2 - 1"
Grinding wheel bore	ø31.75 mm	ø1 1/4"
Spindle speed	3450 rpm	3450 rpm
LONGITUDINAL MOVEMENT
Manual travel	510 mm	20"
CROSS MOVEMENT
Manual travel	230 mm	9"
Handwheel per revolution	5 mm	0.2"
Handwheel per graduation	0.02 mm	0.001"
Microfeed per revolution	0.1 mm	0.004"
Microfeed per graduation	0.001 mm	0.00005"
WHEELHEAD VERTICAL INFEED
Handwheel per revolution	1 mm	0.05"
Handwheel per graduation	0.005 mm	0.0001"
Microfeed per revolution	0.1 mm	0.005"
Microfeed per graduation	0.001 mm	0.00005"
Rapid elevation B39-1102	175 mm/min	8.75"/min
MOTOR
Spindle drive	1.5kW	2hp
GENERAL
Electrical rating	600V 2.5Amp 3Ph 60Hz	600V 2.5Amp 3Ph 60Hz
Electrical approval	CSA SPE-1000	CSA SPE-1000
PHSR exemption letter	valid in Ontario	valid in Ontario
Weight	1050 kg	2314 lb
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.
