MICROWEILY - TY-2680SV

This lathe with its Meehanite cast iron structure provides vibration resistance, high stability and high accuracy. It is equipped with a high precision encoder, rigid servo motor and grade C3 ball screw to ensure high accuracy positioning.
OD turning mode with auto feed and retract function.
ID turning mode with auto feed function and setting to prevent the cutting tool from hitting the chuck.
ARC turning just like a CNC lathe with ability to cut inner and outer arcs.
Taper turning can be performed without a taper attachment. Taper ratio is keyed in with automatic execution.
Threading without limitations, easy to perform Metric, Imperial, DP and MP threads.

Microweily Servo Drive Lathes

CAPACITY	METRIC	IMPERIAL
Distance between centres	2040 mm	80.31"
Swing over bed	660 mm	25.98"
Swing over cross slide	416 mm	16.37"
Swing in gap	760 mm	29.92"
Length of gap in front of face plate	330 mm	13"
Centre height	330 mm	13"
Bed width	400 mm	15.75"
HEADSTOCK
Spindle bore	105 mm	4.13"
Spindle nose	D1-11	D1-11
Spindle taper in nose	MT8	MT8
Spindle taper in sleeve	MT5	MT5
Speed range (12-step)	15 - 1200 rpm	15 - 1200 rpm
CARRIAGE & COMPOUND
Cross slide travel	375 mm	14.75"
Compound rest travel	250 mm	9.84"
TAILSTOCK
Quill diameter	ø75 mm	ø2.95"
Quill travel	160 mm	6.29"
Quill taper	MT5	MT5
MOTORS
Spindle motor	11kW	15hp
Coolant pump	1/8hp	1/8hp
GENERAL
Electrical rating	230V 37Amp 3Ph 60Hz	230V 37Amp 3Ph 60Hz
Electrical approval	CSA SPE-1000	CSA SPE-1000
PHSR exemption letter	valid in Ontario	valid in Ontario
Weight	2580 kg	5687 lb
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.
