MICHAELLIN - U2

Universal Single Lip Cutter Grinder

Features

  • For grinding HHS High Speed Steel and Carbide engraving cutters, single lip and multiple lip cutters of various shapes such as radius, negative tapered and angled profiles. A universal index head is provided with 24 positions so that any particular angle or shape can be obtained with free 360° or 180° rotation.

Specifications: MICHAELLIN - U2

SPECIFICATIONS METRIC IMPERIAL
Max collet capacity ø18 mm ø5/8"
Max grinding diameter ø25mm ø1"
Taper angle 0° - 180° 0° - 180°
Relief angle 0° - 45° 0° - 45°
Negative angle 0° - 25° 0° - 25°
Grinding wheel spindle speed 6000rpm 6000rpm
Cup grinding wheel dimension 100 x 50 x 20mm 4" x 2" x 20mm
Motor 1/3hp 1/3hp
Electrical rating 110V 4Amp 1Ph 60Hz 110V 4Amp 1Ph 60Hz
Electrical approval CSA SPE-1000 CSA SPE-1000
PHSR exemption letter valid in Ontario valid in Ontario
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.

Standard Accessories

  • Set of 7 collets 1/8, 3/16, 1/4, 5/16, 3/8, 1/2 & 5/8"
  • Wheel dresser with diamond
  • Wheel flange
  • Cup grinding wheel
  • Set of wrenches and spanners
  • Wheel spanner
  • Lock pin
  • Aligning finger
