FIRST - V700

CNC Vertical Machining Centre High Speed

Features

High Speed and High Accuracy

  • Meehanite cast iron for all major machine parts.
  • Box type headstock construction provides outstanding cutting capability.
  • 3-Axes high rigidity precision roller guideways.
  • Direct drive spindle achieves excellent finishing surface with low noise and low vibration.
  • Ballscrews directly driven with servo motors.

First V700 NEW (20190115) rpg10.pdf

Specifications: FIRST - V700

Related Products:

TRAVELS METRIC IMPERIAL
X-Axis travel 700 mm 27.55"
Y-Axis travel 400 mm 15.74"
Z-Axis travel 610 mm 24.01"
Distance from spindle nose to table top 150 - 760 mm 5.90 - 29.92"
Guideway type X-Axis linear roller linear roller
Guideway type Y-Axis linear roller linear roller
Guideway type Z-Axis linear roller linear roller
TABLE
Table working surface 800 x 400 mm 31.49 x 15.74"
T-slot number (width x pitch) 3 (18 x 100 mm) 3 (0.70 x 3.93")
Max table load 300 kg 661 lb
FEEDRATE
Rapid traverse X-Axis 48 M/min 1889.76"/min
Rapid traverse Y-Axis 48 M/min 1889.76"/min
Rapid traverse Z-Axis 48 M/min 1889.76"/min
Cutting feedrate 1-10000 mm/min 0.04-394"/min
Min input increment 0.001 mm 0.0001"
SPINDLE
Drive system direct drive direct drive
Spindle motor (30 min rating) 7.5kW (11kW) 10hp (15hp)
Taper BT40/CAT40 BT40/CAT40
Speed range upgrade 12000 rpm upgrade 12000 rpm
Drive range infinitely variable infinitely variable
Max spindle torque
TOOL CHANGER - Arm Type
Tool magazine capacity 24 tools 24 tools
Max tool weight 7 kg 15.43 lb
Max tool length 250 mm 9.84"
Max tool diameter ø80 mm ø3.14"
Max tool diameter (adjacent empty) ø150 mm ø5.90"
Tool selection random random
Tool to tool change time 1.74 sec 1.74 sec
DRIVE MOTORS
Feed drive X-Axis 1.8kW 2.5hp
Feed drive Y-Axis 1.8kW 2.5hp
Feed drive Z-Axis 3kW 4hp
GENERAL
Electrical approval CSA SPE-1000 CSA SPE-1000
Power required 15kVA 15kVA
Voltage required 600V or 220V 600V or 220V
Air pressure required 5-7 bar 75-110 psi
Coolant tank capacity 200 L 52.83 US gal
CONTROLLER
CNC Control FANUC FANUC
The manufacturer reserves the right to modify the design, specifications and/or colour of the machine without prior notice.

Standard Accessories

  • #40 24-tool CAM type ATC
  • Automatic lubrication system
  • Enclosed splash guard
  • Coolant system
  • Coolant tank and chip collector
  • Spindle oil chiller
  • Chip flush/wash system
  • Chip auger, back centre discharge
  • Removeable MPG manual pulse generator
  • Electric cabinet exhaust fan
  • Call light (3-color)
  • LED Work light
  • Levelling bolts, nuts & pads
  • Tool kit

Included Accessories

  • 12000rpm direct drive spindle
  • Set of pull studs
  • Air gun
  • Oil skimmer
  • External air blast
  • Automatic power off
  • Door inter-lock safety switch
  • Transformer

Optional Accessories

  • #40 30-tool ATC
  • 15000rpm direct drive spindle
  • Coolant through spindle system (20 bar)
  • Coolant through spindle system (50 bar)
  • Air through spindle system
  • Oil mist collection system
  • Chip conveyor-spiral (screw) type, back L side discharge + bin
  • Chip conveyor-flat type, back L/R side discharge + bin
  • 4th axis connector ready
  • 4th axis rotary table
  • 4th + 5th axis connector ready
  • 4th + 5th axis rotary table
  • Automatic tool measuring device
  • Automatic workpiece measuring device
  • Linear scale
